York EX Series User Manual

JOHNSON CONTROLS
44
FORM 155.32-ICOM1.EN.GB
ISSUE DATE: 10/13/2017
SECTION 4 - TECHNICAL DATA
TABLE 17 - SPLIT SHIPMENT - STANDARD EFFICIENCY - CGN
DOUBLE EFFECT STEAM FIRED ABSORPTION CHILLER
YHAU-CGN
MAIN SHELL UNIT HX UNIT HG UNIT
Length
(m)
Width
(m)
Height
(m)
Weight
(ton)
Length
(m)
Width
(m)
Height
(m)
Weight
(ton)
Length
(m)
Width
(m)
Height
(m)
Weight
(ton)
120EXS
150EXS 2.6 2.0 2.3 4.0 2.6 1.5 1.2 0.7 2.8 1.0 1.5 1.5
180EXS 3.2 2.0 2.3 4.5 3.2 1.5 1.2 0.7 3.1 1.0 1.5 1.5
240EXS 3.8 2.0 2.3 4.7 3.4 1.5 1.1 0.7 3.6 1.0 1.5 1.8
300EXS 4.7 2.0 2.3 5.8 4.2 1.5 1.1 0.8 4.0 1.0 1.5 2.2
360EXS 5.8 2.0 2.3 6.8 5.7 1.5 1.1 1.2 5.1 1.0 2.0 2.6
400EXS 6.3 2.0 2.3 7.0 6.2 1.5 1.1 1.2 5.6 1.0 2.0 2.7
450EXS 4.9 2.3 2.8 9.8 4.7 1.6 1.1 1.2 4.7 1.0 2.0 2.7
500EXS 5.4 2.3 2.8 10.0 5.2 1.6 1.1 1.2 4.8 1.4 2.0 3.4
560EXS 5.9 2.3 2.8 11.1 5.7 1.6 1.1 1.2 5.1 1.4 2.0 3.5
600EXS 6.4 2.5 2.8 12.2 6.2 1.6 1.1 1.2 5.2 1.4 2.0 3.9
700EXS 7.2 2.5 2.8 14.8 7.0 1.6 1.1 1.4 5.9 1.4 2.0 4.0
800EXS 7.9 2.5 2.8 17.6 7.7 1.6 1.1 1.6 6.6 1.4 2.0 4.5
900EXWS 7.3 2.6 2.8 20.6 6.7 1.8 1.1 1.7 5.9 1.7 2.8 5.8
1000EXWS 8.0 2.6 2.8 22.3 7.3 1.8 1.1 1.8 5.9 1.7 2.8 5.8
1100EXWS 8.7 2.6 2.8 24.8 8.0 1.8 1.1 1.8 6.5 1.7 2.8 6.8
1200EXW3S 9.0 2.6 2.9 25.9 8.0 1.8 1.1 1.8 6.5 1.7 2.8 6.8
1300EXW3S 9.5 2.6 3.2 27.7 8.5 1.8 1.1 2.2 6.8 1.7 2.8 7.0
1400EXW3S 10.0 2.6 3.2 29.5 9.0 1.8 1.1 2.2 6.8 1.7 2.8 7.0
1500EXW3S 10.5 2.6 3.2 31.3 9.5 1.8 1.1 2.9 7.2 2.0 3.2 10.5
1600EXW3S 11.0 2.6 3.2 33.1 10.0 1.8 1.1 3.0 7.2 2.0 3.2 10.5
