JOHNSON CONTROLS
38
FORM 155.32-ICOM1.EN.GB
ISSUE DATE: 10/13/2017
SECTION 4 - TECHNICAL DATA
TABLE 11 - LOAD POINTS FOR HIGH EFFICIENCY - CGN
YHAU-CGN LOAD POINT 1 LOAD POINT 2 LOAD POINT 3 LOAD POINT 4
120EXH 2.38 1.95 2.93 1.49
150EXH 2.38 1.95 2.93 1.49
180EXH 2.86 2.27 3.41 1.81
240EXH 2.95 2.64 3.96 2.00
300EXH 3.71 2.99 4.48 2.29
360EXH 4.54 3.51 5.27 2.73
400EXH 5.09 3.93 5.89 3.03
450EXH 5.55 4.01 6.01 3.19
500EXH 6.14 3.96 5.95 4.00
560EXH 7.03 4.70 7.06 4.14
600EXH 7.55 4.88 7.31 4.76
700EXH 8.12 5.47 8.20 5.21
800EXH 10.14 6.34 9.51 6.58
900EXWH 11.2 6.58 9.87 7.46
1000EXWH 13.0 7.81 11.7 8.63
1100EXWH 13.8 9.05 13.6 8.95
1200EXW3H 13.6 9.97 15.0 9.23
1300EXW3H 14.9 10.30 15.5 10.7
1400EXW3H 15.7 10.9 16.3 11.2
1500EXW3H 16.7 10.9 16.4 12.5
1600EXW3H 17.2 10.6 15.9 13.5
