SECTION 4 - TECHNICAL DATA
UPPER COMMUNICATION SPECIFICATION
The information in this section applies to the CG Se-
ries of direct fired absorption chiller-heaters.
Upper Communication System Configuration
The configuration of the upper communication system
is shown in Figure 20 on page 68
Central Monitoring Unit
Data concentrator (HUB)
Scope of delivery
by customer
Scope of delivery by
Johnson Controls
Absorption chiller-heater control panel
FIGURE 20 - UPPER COMMUNICATION SYSTEM CONFIGURATION
