JOHNSON CONTROLS
71
SECTION 4 - TECHNICAL DATA
FORM 155.32-ICOM1.EN.GB
ISSUE DATE: 10/13/2017
4
MEASUREMENT VALUE
15 Chilled/Hot water inlet temp. 12.0 °C 00083 0001~4000 unit, 1 unit=0.1°C
16 Chilled/Hot water outlet temp. 7.0 °C 00085 0001~4000 unit, 1 unit=0.1°C
17 Refrigerant temp. at evaporator 5.0 °C 00087 0001~4000 unit, 1 unit=0.1°C
18 Cooling water inlet temp. 32.0 °C 00089 0001~4000 unit, 1 unit=0.1°C
19 Cooling water outlet temp 37.0 °C 00091 0001~4000 unit, 1 unit=0.1°C
20 Absorber solution temp. 38.0 °C 00093 0001~4000 unit, 1 unit=0.1°C
21 High temperature generator
solution temp.
145.0 °C 00095 0001~4000 unit, 1 unit=0.1°C
22 Exhaust gas temp. 220.0 °C 00097 0001~4000 unit, 1 unit=0.1°C
23 High temperature generator
pressure
70.0 kPa 00099 0001~1100 unit, 1 unit=0.1 kPa
24 Motor opening rate 100.0 % 00101 0001~1100 unit, 1 unit=0.1%
25 High temperature generator
concentration
62.0 % 00103 0001~1100 unit, 1 unit=0.1%
26 Purge tank pressure 2.0 kPa 00105 0001~4000 unit, 1 unit=0.1 kPa
TABLE 24 - WRITE COMMAND
ITEM ADDRESS CONTENT
1 Chiller-heater operation signal 02001 ON at CHILLER-HEATER OPERATION,
PULSE SIGNAL
2 Chiller-heater stop signal 02002 ON at CHILLER-HEATER STOP, PULSE
SIGNAL
3 Set point 00203 0050~1000 unit, 1 unit=0.1°C
TABLE 13 - READ COMMAND (CONT.)
