JOHNSON CONTROLS
69
SECTION 4 - TECHNICAL DATA
FORM 155.32-ICOM1.EN.GB
ISSUE DATE: 10/13/2017
4
Scope of Delivery
Johnson Controls scope of delivery for the upper com-
munication system covers the control panels for the
upper communication function. The customer is re-
sponsible to deliver all other related equipment: con-
centrator (HUB), installation, wiring, communication
program for the central monitoring unit, etc. See Table
10 on page 36 for more information.
TABLE 20 - SCOPE OF DELIVERY
ITEM CUSTOMER JCI REMARKS
Control panel with
upper communication
function
X Communication protocol: Modbus TCP
Data concentrator
(HUB)
X Installation and wiring are included
Wiring work for Ethernet
connection
X Apply twisted pair cable
Communication
program for central
monitoring unit
X See Table 11 on page 38 and Table 12 on
page 39 for the details of the IP address,
function code, communication data address,
etc.
Connection Port for Ethernet Communication
Make sure that the Ethernet cable is plugged into the
correct port on the Control Panel. The Ethernet con-
nection port is located at the bottom left on the back of
the Control Panel.
ITEM SPECIFICATION
Communication format 10BASE-T/100BASE-TX
Connector shape RJ-45 type modular jack connector
LED function
Active
(Green)
Blink Data sending/receiving
No light No data sending/receiving
Link
(Green)
Blink Data sending/receiving via
10BASE-T/100BASE-TX
No light No connection or successor job
failure
TABLE 21 - ETHERNET INTERFACE SPECIFICATION
