York EX Series User Manual

JOHNSON CONTROLS
45
SECTION 4 - TECHNICAL DATA
FORM 155.32-ICOM1.EN.GB
ISSUE DATE: 10/13/2017
4
TABLE 18 - SPLIT SHIPMENT - STANDARD EFFICIENCY - CGH
DOUBLE EFFECT STEAM FIRED ABSORPTION CHILLER
YHAU-CGH
MAIN SHELL UNIT HX UNIT HG UNIT
Length
(m)
Width
(m)
Height
(m)
Weight
(ton)
Length
(m)
Width
(m)
Height
(m)
Weight
(ton)
Length
(m)
Width
(m)
Height
(m)
Weight
(ton)
120EXS
150EXS
180EXS
240EXS
300EXS
360EXS
400EXS
450EXS 5.4 2.3 2.8 10.0 5.2 1.6 1.1 1.2 4.8 1.4 2.0 3.9
500EXS 5.9 2.3 2.8 11.1 5.7 1.6 1.1 1.2 5.1 1.4 2.0 3.9
560EXS 6.4 2.5 2.8 12.2 6.2 1.6 1.1 1.2 5.2 1.4 2.0 4.5
600EXS 7.2 2.5 2.8 14.8 7.0 1.6 1.1 1.4 5.9 1.4 2.0 4.5
700EXS 7.9 2.5 2.8 17.6 7.7 1.6 1.1 1.6 6.6 1.7 2.8 7.0
800EXS 7.3 2.6 2.8 20.6 6.7 1.8 1.1 1.7 5.9 1.7 2.8 6.8
900EXWS 8.0 2.6 2.8 22.3 7.3 1.8 1.1 1.8 5.9 1.7 2.8 6.8
1000EXWS 8.7 2.6 2.8 24.8 8.0 1.8 1.1 1.8 6.5 1.7 2.8 7.0
1100EXWS 9.0 2.6 2.9 25.9 8.0 1.8 1.1 1.8 6.5 1.7 2.8 7.0
1200EXW3S 9.5 2.6 3.2 27.7 8.5 1.8 1.1 2.2 6.8 2.0 3.2 10.5
1300EXW3S 10.0 2.6 3.2 29.5 9.0 1.8 1.1 2.2 6.8 2.0 3.2 10.5
1400EXW3S 10.5 2.6 3.2 31.3 9.5 1.8 1.1 2.9 7.2 2.0 3.2 13.1
1500EXW3S 11.0 2.6 3.2 33.1 10.0 1.8 1.1 3.0 7.2 2.0 3.2 13.1
1600EXW3S 11.0 2.6 3.2 33.1 10.0 1.8 1.1 3.0 7.2 2.0 3.2 13.1
