York EX Series User Manual

JOHNSON CONTROLS
43
SECTION 4 - TECHNICAL DATA
FORM 155.32-ICOM1.EN.GB
ISSUE DATE: 10/13/2017
4
TABLE 16 - SPLIT SHIPMENT - HIGH EFFICIENCY - CGH
DOUBLE EFFECT STEAM FIRED ABSORPTION CHILLER
YHAU-CGH
MAIN SHELL UNIT HX UNIT HG UNIT
Length
(m)
Width
(m)
Height
(m)
Weight
(ton)
Length
(m)
Width
(m)
Height
(m)
Weight
(ton)
Length
(m)
Width
(m)
Height
(m)
Weight
(ton)
120EXH
150EXH
180EXH
240EXH
300EXH
360EXH
400EXH
450EXH
4.9 2.3 2.8 9.8 4.7 1.6 1.1 2.3 4.7 1.4 2.0 3.4
500EXH
5.4 2.3 2.8 10.0 5.2 1.6 1.1 2.5 4.8 1.4 2.0 3.9
560EXH
5.9 2.3 2.8 11.1 5.7 1.6 1.1 2.7 5.1 1.4 2.0 3.9
600EXH
6.4 2.5 2.8 12.2 6.2 1.6 1.1 2.9 5.2 1.4 2.0 4.5
700EXH
7.2 2.5 2.8 14.8 7.0 1.6 1.1 3.2 5.9 1.4 2.0 4.5
800EXH
7.9 2.5 2.8 17.6 7.7 1.6 1.1 3.5 6.6 1.7 2.8 7.0
900EXWH
7.3 2.6 2.8 20.6 6.7 1.8 1.1 3.1 5.9 1.7 2.8 6.8
1000EXWH
8.0 2.6 2.8 22.3 7.3 1.8 1.1 3.3 5.9 1.7 2.8 6.8
1100EXWH
8.7 2.6 2.8 24.8 8.0 1.8 1.1 3.6 6.5 1.7 2.8 7.0
1200EXW3H
9.0 2.6 2.9 25.9 8.0 1.8 1.1 3.6 6.5 1.7 2.8 7.0
1300EXW3H
9.5 2.6 3.2 27.7 8.5 1.8 1.1 3.8 6.8 2.0 3.2 10.5
1400EXW3H
10.0 2.6 3.2 29.5 9.0 1.8 1.1 4.8 6.8 2.0 3.2 10.5
1500EXW3H
10.5 2.6 3.2 31.3 9.5 1.8 1.1 6.0 7.2 2.0 3.2 13.1
1600EXW3H
11.0 2.6 3.2 33.1 10.0 1.8 1.1 6.3 7.2 2.0 3.2 13.1
