York YLUA0078 - FIGURE 22 - UNIT KEYS PROGRAMMING QUICK REFERENCE LIST

JOHNSON CONTROLS
129
SECTION 7 – UNIT CONTROLS
FORM 150.73-NM1
ISSUE DATE: 09/04/2020
7
FIGURE 22 - UNIT KEYS PROGRAMMING QUICK REFERENCE LIST
Figure 22 provides a quick reference list for the Unit key setpoints.
LD13348
Options Key
(Press Options Key
to Adv.)
Display Language
Expansion Valve Type
(Thermoplastic or Electric)
(Programmed Under Service
Mode, Viewable Only)
Must be Programmed
for Thermostatic
Ambient Control
(Standard or Low)
Local/Remote Mode
Unit Control Mode
(DAT or Suct Press)
Display Units
(English or Metric)
System Lead/Lag Control
(Manual or Automatic)
Fan Control Mode
Manual Override Mode
Current Feedback Option
Soft Start Option
Power Failure Restart
Unit Type
"Condensing Unit" MUST be
Selected Via Jumper Installed
(Viewable Only)
Refrigerant Type R410A
(Programmed Under Service Mode)
(Viewable Only
System Switches
On/Off
Flashcard Data Logging
Hot Gas Bypass Type
