York YLUA0078 User Manual

JOHNSON CONTROLS
163
SECTION 10 – MAINTENANCE
FORM 150.73-NM1
ISSUE DATE: 09/04/2020
10
TABLE 51 - R-410A PRESSURE TEMPERATURE
CHART
PSIG TEMP ˚F PSIG TEMP ˚F
0 -60 78 20
2 -58 80 21
4 -54 85 24
6 -50 90 26
8 -46 95 29
10 -42 100 32
12 -39 105 34
14 -36 110 36
16 -33 115 39
18 -30 120 41
20 -28 125 43
22 -26 130 45
24 -24 135 47
26 -20 140 49
28 -18 145 51
30 -16 150 53
32 -14 160 57
34 -12 170 60
36 -10 180 64
38 -8 190 67
40 -6 200 70
42 -4 210 73
44 -3 220 76
46 -2 225 78
48 0 235 80
50 1 245 83
52 3 255 85
54 4 265 88
56 6 275 90
58 7 285 92
60 8 295 95
62 10 305 97
64 11 325 101
66 13 355 108
68 14 375 112
70 15 405 118
72 16 500 134
74 17 600 149
76 19 700 159
TABLE 50 - PRESSURE CONVERSION CHART -
GAUGE OR DIFFERENTIAL
PSI = BAR BAR = PSI
20
30
40
1.38
2.07
2.76
1.5
2
2.5
21.8
29
36.3
50
60
70
3.45
4.14
4.83
3
3.5
4
43.5
50.8
58
80
90
100
5.52
6.21
6.9
4.5
5
5.5
65.3
72.5
79.8
110
120
130
7.59
8.28
8.97
6
6.5
7
87
94.3
101.5
140
150
160
9.66
10.34
11.03
7.5
8
8.5
108.8
116
123.3
170
180
190
11.72
12.41
13.1
9
9.5
10
130.5
137.8
145
200
210
220
13.79
14.48
15.17
10.5
11
11.5
152.3
159.5
166.8
230
240
250
15.86
16.55
17.24
12
12.5
13
174
181.3
188.5
260
270
280
17.93
18.62
19.31
13.5
14
14.5
195.8
203
210.3
290
300
310
20
20.69
21.38
15
15.5
16
217.5
224.8
232
320
330
340
22.07
22.76
23.45
16.5
17
17.5
239.3
246.5
253.8
350
360
370
24.14
24.83
25.52
18
18.5
19
261
268.3
275.5
380
390
400
26.21
26.9
27.59
19.5
20
20.5
282.8
290
297.3
