York YLUA0078 User Manual

JOHNSON CONTROLS
54
FORM 150.73-NM1
ISSUE DATE: 09/04/2020
SECTION 5 – TECHNICAL DATA
TABLE 20 - LUG SIZING
MODEL
NON-FUSE DISC SW. CIRCUIT BREAKER TERMINAL BLOCK
RATING SIZE LUG RATING SIZE LUG LUG
0078
600 S6-600 S6: (2) 250kcmil - 500kcmil 400 S5-400 S5: (2) 3/0 - 250kcmil (4) 4AWG - 500kcmil
600 S6-600 S6: (2) 250kcmil - 500kcmil 400 S5-400 S5: (2) 3/0 - 250kcmil (4) 4AWG - 500kcmil
250 S4-250 S4: 6AWG - 350kcmil 200 S3-225 S3-S4-S5: 4AWG - 300kcmil (2) 4AWG - 500kcmil
200 S3-225 S3-S4-S5: 4AWG - 300kcmil 175 S3-175 S3-S4-S5: 4AWG - 300kcmil (2) 4AWG - 500kcmil
200 S3-225 S3-S4-S5: 4AWG - 300kcmil 150 S3-150 S3-S4: 2AWG - 4/0 (2) 4AWG - 500kcmil
0088
600 S6-600 S6: (2) 250kcmil - 500kcmil 400 S5-400 S5: (2) 3/0 - 250kcmil (4) 4AWG - 500kcmil
600 S6-600 S6: (2) 250kcmil - 500kcmil 400 S5-400 S5: (2) 3/0 - 250kcmil (4) 4AWG - 500kcmil
400 S5-400 S5: (2) 3/0 - 250kcmil 250 S4-250 S4: 6AWG - 350kcmil (2) 4AWG - 500kcmil
250 S4-250 S4: 6AWG - 350kcmil 200 S3-225 S3-S4-S5: 4AWG - 300kcmil (2) 4AWG - 500kcmil
200 S3-225 S3-S4-S5: 4AWG - 300kcmil 175 S3-175 S3-S4-S5: 4AWG - 300kcmil (2) 4AWG - 500kcmil
0095
600 S6-600 S6: (2) 250kcmil - 500kcmil 500 S6-600 S6: (2) 250kcmil - 500kcmil (4) 4AWG - 500kcmil
600 S6-600 S6: (2) 250kcmil - 500kcmil 450 S6-600 S6: (2) 250kcmil - 500kcmil (4) 4AWG - 500kcmil
400 S5-400 S5: (2) 3/0 - 250kcmil 300 S5-400 S5: (2) 3/0 - 250kcmil (2) 4AWG - 500kcmil
250 S4-250 S4: 6AWG - 350kcmil 225 S3-225 S3-S4-S5: 4AWG - 300kcmil (2) 4AWG - 500kcmil
250 S4-250 S4: 6AWG - 350kcmil 200 S3-225 S3-S4-S5: 4AWG - 300kcmil (2) 4AWG - 500kcmil
0098
600 S6-600 S6: (2) 250kcmil - 500kcmil 500 S6-600 S6: (2) 250kcmil - 500kcmil (4) 4AWG - 500kcmil
600 S6-600 S6: (2) 250kcmil - 500kcmil 500 S6-600 S6: (2) 250kcmil - 500kcmil (4) 4AWG - 500kcmil
400 S5-400 S5: (2) 3/0 - 250kcmil 300 S5-400 S5: (2) 3/0 - 250kcmil (2) 4AWG - 500kcmil
250 S4-250 S4: 6AWG - 350kcmil 250 S4-250 S4: 6AWG - 350kcmil (2) 4AWG - 500kcmil
250 S4-250 S4: 6AWG - 350kcmil 225 S3-225 S3-S4-S5: 4AWG - 300kcmil (2) 4AWG - 500kcmil
0108
600 S6-600 S6: (2) 250kcmil - 500kcmil 500 S6-600 S6: (2) 250kcmil - 500kcmil (4) 4AWG - 500kcmil
600 S6-600 S6: (2) 250kcmil - 500kcmil 500 S6-600 S6: (2) 250kcmil - 500kcmil (4) 4AWG - 500kcmil
400 S5-400 S5: (2) 3/0 - 250kcmil 350 S5-400 S5: (2) 3/0 - 250kcmil (2) 4AWG - 500kcmil
400 S5-400 S5: (2) 3/0 - 250kcmil 250 S4-250 S4: 6AWG - 350kcmil (2) 4AWG - 500kcmil
250 S4-250 S4: 6AWG - 350kcmil 225 S3-225 S3-S4-S5: 4AWG - 300kcmil (2) 4AWG - 500kcmil
0130
800 S6-800 S6: (3) 2/0 - 400kcmil 600 S6-600 S6: (2) 250kcmil - 500kcmil (4) 4AWG - 500kcmil
800 S6-800 S6: (3) 2/0 - 400kcmil 600 S6-600 S6: (2) 250kcmil - 500kcmil (4) 4AWG - 500kcmil
400 S5-400 S5: (2) 3/0 - 250kcmil 350 S5-400 S5: (2) 3/0 - 250kcmil (4) 4AWG - 500kcmil
400 S5-400 S5: (2) 3/0 - 250kcmil 300 S5-400 S5: (2) 3/0 - 250kcmil (2) 4AWG - 500kcmil
400 S5-400 S5: (2) 3/0 - 250kcmil 250 S4-250 S4: 6AWG - 350kcmil (2) 4AWG - 500kcmil
0148
800 S6-800 S6: (3) 2/0 - 400kcmil 700 S6-800 S6: (3) 2/0 - 400kcmil (4) 4AWG - 500kcmil
800 S6-800 S6: (3) 2/0 - 400kcmil 700 S6-800 S6: (3) 2/0 - 400kcmil (4) 4AWG - 500kcmil
600 S6-600 S6: (2) 250kcmil - 500kcmil 400 S5-400 S5: (2) 3/0 - 250kcmil (4) 4AWG - 500kcmil
400 S5-400 S5: (2) 3/0 - 250kcmil 350 S5-400 S5: (2) 3/0 - 250kcmil (2) 4AWG - 500kcmil
400 S5-400 S5: (2) 3/0 - 250kcmil 300 S5-400 S5: (2) 3/0 - 250kcmil (2) 4AWG - 500kcmil
0158
800 S6-800 S6: (3) 2/0 - 400kcmil 700 S6-800 S6: (3) 2/0 - 400kcmil (4) 4AWG - 500kcmil
800 S6-800 S6: (3) 2/0 - 400kcmil 700 S6-800 S6: (3) 2/0 - 400kcmil (4) 4AWG - 500kcmil
600 S6-600 S6: (2) 250kcmil - 500kcmil 450 S6-600 S6: (2) 250kcmil - 500kcmil (4) 4AWG - 500kcmil
400 S5-400 S5: (2) 3/0 - 250kcmil 350 S5-400 S5: (2) 3/0 - 250kcmil (4) 4AWG - 500kcmil
400 S5-400 S5: (2) 3/0 - 250kcmil 300 S5-400 S5: (2) 3/0 - 250kcmil (2) 4AWG - 500kcmil
