SECTION 5 – TECHNICAL DATA
SINGLE POINT
TABLE 12 - STANDARD EFFICIENCY UNIT ELECTRICAL DATA (6 COMPR)
MODEL E󰀨.
Pump
Model
Volt
Code
Pump
FLA
MCA
MIN
N/F DS
MIN
DUAL
ELEM
FUSE
MAX
DUAL
ELEM
FUSE
MAX
CB
SYSTEM # 1 SYSTEM # 1 SYSTEM # 2
COMPR 1 COMPR 2 COMPR 3 FAN COMPR 1 COMPR 2 COMPR 3 FAN
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
0078 SE X
17 351 400 400 400 51 300 51 300 51 300 2 7.6 44.0 51 300 51 300 51 300 2 7.6 44.0
23 350 400 400 400 51 300 51 300 51 300 2 7.4 37.0 51 300 51 300 51 300 2 7.4 37.0
40 186 250 200 200 27 139 27 139 27 139 2 4.5 23.1 27 139 27 139 27 139 2 4.5 23.1
46 160 200 175 175 23 150 23 150 23 150 2 4.0 19.0 23 150 23 150 23 150 2 4.0 19.0
58 136 200 150 150 20 109 20 109 20 109 2 2.9 15.3 20 109 20 109 20 109 2 2.9 15.3
0088 SE X
17 366 600 400 400 56 425 56 425 56 425 2 7.6 44.0 51 300 51 300 51 300 2 7.6 44.0
23 365 600 400 400 56 425 56 425 56 425 2 7.4 37.0 51 300 51 300 51 300 2 7.4 37.0
40 216 250 225 250 36 239 36 239 36 239 2 4.5 23.1 27 139 27 139 27 139 2 4.5 23.1
46 173 200 200 200 27 187 27 187 27 187 2 4.0 19.0 23 150 23 150 23 150 2 4.0 19.0
58 148 200 175 175 24 148 24 148 24 148 2 2.9 15.3 20 109 20 109 20 109 2 2.9 15.3
TABLE 13 - HIGH EFFICIENCY UNIT ELECTRICAL DATA (4 COMPR)
MODEL E󰀨.
Pump
Model
Volt
Code
Pump
FLA
MCA
MIN
N/F
DS
MIN
DUAL
ELEM
FUSE
MAX
DUAL
ELEM
FUSE
MAX
CB
SYSTEM # 1 SYSTEM # 1 SYSTEM # 2
COMPR 1 COMPR 2 COMPR 3 FAN COMPR 1 COMPR 2 COMPR 3 FAN
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
0098 HE X
17 404 600 450 500 110 599 56 425 3 7.6 44.0 110 599 56 425 3 7.6 44.0
23 403 600 450 500 110 358 56 425 3 7.4 37.0 110 599 56 425 3 7.4 37.0
40 255 400 300 300 69 310 36 239 3 4.5 23.1 69 358 36 239 3 4.5 23.1
46 200 250 225 250 55 239 27 187 3 4.0 19.0 55 310 27 187 3 4.0 19.0
58 176 200 200 225 49 310 24 148 3 2.9 15.3 49 239 24 148 3 2.9 15.3
TABLE 14 - HIGH EFFICIENCY UNIT ELECTRICAL DATA (5 COMPR)
MODEL E󰀨.
Pump
Model
Volt
Code
Pump
FLA
MCA
MIN
N/F
DS
MIN
DUAL
ELEM
FUSE
MAX
DUAL
ELEM
FUSE
MAX
CB
SYSTEM # 1 SYSTEM # 1 SYSTEM # 2
COMPR 1 COMPR 2 COMPR 3 FAN COMPR 1 COMPR 2 COMPR 3 FAN
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
0108 HE X
17 460 600 500 500 56 425 56 425 56 425 2 7.6 44.0 110 599 110 599 4 7.6 44.0
23 458 600 500 500 56 425 56 425 56 425 2 7.4 37.0 110 599 110 599 4 7.4 37.0
40 291 400 350 350 36 239 36 239 36 239 2 4.5 23.1 69 358 69 358 4 4.5 23.1
46 227 250 250 250 27 187 27 187 27 187 2 4.0 19.0 55 310 55 310 4 4.0 19.0
58 200 250 225 225 24 148 24 148 24 148 2 2.9 15.3 49 239 49 239 4 2.9 15.3
