JOHNSON CONTROLS
22
FORM 150.73-NM1
ISSUE DATE: 09/04/2020
SECTION 2 – PRODUCT DESCRIPTION
FIGURE 4 - POWER PANEL / CONTROL COMPONENTS
COMPRESSOR
OVERLOADS
COMPRESSOR
CONTACTORS
FAN CONTACTORS
FAN FUSES
CONTROL
RELAY
MICROCOMPUTER
CONTROL
CENTER
MICROPANEL
DISPLAY
KEYPAD
XTBC1
XTBC2
XTBF2
MICROBOARD
LD13248
