SECTION 9 – SERVICE AND TROUBLESHOOTING
Discharge Air Temperature Sensor
J6-5 = +5 VDC regulated supply to sensor.
J6-8 = vdc input signal to the microboard.
See Table 36 on page 146 for voltage
readings that correspond to specific
discharge temperatures.
J6-2 = drain (shield connection = 0 VDC)
Analog Inputs – Pressure
Refer to the unit wiring diagram. Pressure inputs are
connected to the microboard on plugs J7 and J9. These
analog inputs represent varying dc signals correspond-
ing to varying pressures. All voltages are in reference
to the unit case (ground).
System 1 discharge and suction pressures will be con-
nected to J7 of the microboard. System 2 discharge and
suction pressure transducers will be connected to J9 of
the microboard.
The discharge transducers are optional on all units. If
the discharge transducers are not installed, no connec-
tions are made to the microboard and the discharge
pressure readout on the display would be zero.
The suction pressure transducers are standard on all
YLUA’s. The suction pressure transducers have a range
of 0 psig to 400 psig. The output will be linear from 0.5
VDC to 4.5 VDC over the 400 psig (27.5 barg) range.
The discharge transducers have a range from 0 psig to
650 psig. The output will be linear from 0.5 VDC to 4.5
VDC over the 650 psig (41.25 barg) range. Following
is the formula that can be used to verify the voltage
output of the transducer. All voltage reading are in ref-
erence to ground (unit case).
TABLE 36 - DISCHARGE AIR TEMPERATURE
SENSOR TEMPERATURE/VOLTAGE/RESISTANCE
CORRELATION
TEMP °F VOLTAGE RESISTANCE TEMP °C
0 1.71 25619 -18
2 1.78 24046 -17
4 1.85 22580 -16
6 1.93 21214 -14
8 2.00 19939 -13
10 2.07 18749 -12
12 2.15 17637 -11
14 2.22 16599 -10
16 2.30 15629 -9
18 2.37 14721 -8
20 2.45 13872 -7
22 2.52 13077 -6
24 2.59 12333 -4
26 2.67 11636 -3
28 2.74 10982 -2
30 2.81 10370 -1
32 2.88 9795 0
34 2.95 9256 1
36 3.02 8750 2
38 3.08 8276 3
40 3.15 7830 4
42 3.21 7411 6
44 3.27 7017 7
46 3.33 6647 8
48 3.39 6298 9
50 3.45 5970 10
52 3.51 5661 11
54 3.56 5370 12
56 3.61 5096 13
58 3.67 4837 14
60 3.72 4593 16
62 3.76 4363 17
64 3.81 4145 18
66 3.86 3941 19
68 3.90 3747 20
70 3.94 3564 21
72 3.98 3392 22
74 4.02 3228 23
76 4.06 3074 24
78 4.10 2928 26
80 4.13 2790 27
