FORM 150.73-NM1
ISSUE DATE: 09/04/2020
SECTION 5 – TECHNICAL DATA
ELECTRICAL DATA
TABLE 10 - STANDARD EFFICIENCY UNIT ELECTRICAL DATA (4 COMPR)
MODEL EFF.
PUMP
MODEL
VOLT
CODE
PUMP
FLA
MCA
MIN
N/F
DS
MIN
DUAL
ELEM
FUSE
MAX
DUAL
ELEM
FUSE
MAX
CB
SYSTEM # 1 SYSTEM # 1 SYSTEM # 2
COMPR 1 COMPR 2 COMPR 3 FAN COMPR 1 COMPR 2 COMPR 3 FAN
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
0130 SE X
17 511 600 600 600 110 599 110 599 3 7.6 44.0 110 599 110 599 3 7.6 44.0
23 510 600 600 600 110 599 110 599 3 7.4 37.0 110 599 110 599 3 7.4 37.0
40 321 400 350 350 69 358 69 358 3 4.5 23.1 69 358 69 358 3 4.5 23.1
46 255 400 300 300 55 310 55 310 3 4.0 19.0 55 310 55 310 3 4.0 19.0
58 227 250 250 250 49 239 49 239 3 2.9 15.3 49 239 49 239 3 2.9 15.3
SINGLE POINT
TABLE 11 - STANDARD EFFICIENCY UNIT ELECTRICAL DATA (5 COMPR)
MODEL e󰀨.
Pump
Model
Volt
Code
Pump
FLA
MCA
MIN
N/F
DS
MIN
DUAL
ELEM
FUSE
MAX
DUAL
ELEM
FUSE
MAX
CB
SYSTEM # 1 SYSTEM # 1 SYSTEM # 2
COMPR 1 COMPR 2 COMPR 3 FAN COMPR 1 COMPR 2 COMPR 3 FAN
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
0095 SE X
17 391 600 450 500 56 425 56 425 56 425 2 7.6 44.0 110 599 56 425 2 7.6 44.0
23 390 600 450 450 56 425 56 425 56 425 2 7.4 37.0 110 599 56 425 2 7.4 37.0
40 249 400 300 300 36 239 36 239 36 239 2 4.5 23.1 69 358 36 239 2 4.5 23.1
46 192 250 225 225 27 187 27 187 27 187 2 4.0 19.0 55 310 27 187 2 4.0 19.0
58 168 200 200 200 24 148 24 148 24 148 2 2.9 15.3 49 239 24 148 2 2.9 15.3
0148 SE X
17 582 800 700 700 110 599 110 599 110 599 4 7.6 44.0 110 599 56 425 4 7.6 44.0
23 581 800 700 700 110 599 110 599 110 599 4 7.4 37.0 110 599 56 425 4 7.4 37.0
40 366 600 400 400 69 358 69 358 69 358 4 4.5 23.1 69 358 36 239 4 4.5 23.1
46 291 400 350 350 55 310 55 310 55 310 4 4.0 19.0 55 310 27 187 4 4.0 19.0
58 257 400 300 300 49 239 49 239 49 239 4 2.9 15.3 49 239 24 148 4 2.9 15.3
0158 SE X
17 636 800 700 700 110 599 110 599 110 599 4 7.6 44.0 110 599 110 599 4 7.6 44.0
23 635 800 700 700 110 599 110 599 110 599 4 7.4 37.0 110 599 110 599 4 7.4 37.0
40 399 600 450 450 69 358 69 358 69 358 4 4.5 23.1 69 358 69 358 4 4.5 23.1
46 318 400 350 350 55 310 55 310 55 310 4 4.0 19.0 55 310 55 310 4 4.0 19.0
58 283 400 300 300 49 239 49 239 49 239 4 2.9 15.3 49 239 49 239 4 2.9 15.3
