York YLUA0078 User Manual

JOHNSON CONTROLS
155
SECTION 10 – MAINTENANCE
FORM 150.73-NM1
ISSUE DATE: 09/04/2020
10
TABLE 40 – ISN TRANSMITTED DATA (CONT’D)
TABLE 40 – ISN TRANSMITTED DATA (CONT’D)
ISN
PAGE
CHARACTER TYPE DATA
P37 109 Digital SYS 2 Alarm
P38 110 Digital
Evaporator Heater
Status
P39 111 Digital
Evaporator Pump
Status
P40 112 Digital SYS 1 Comp. 2 Run
P41 113 Digital SYS 2 Comp. 2 Run
P42 114 Digital
SYS 1 Liquid Line
Solenoid Valve or EEV
Pilot Solenoid
P43 115 Digital
SYS 1 Hot Gas
Bypass Valve
P44 116 Digital SYS 1 Comp. 2 Run
P45 117 Digital SYS 2 Comp. 2 Run
P46 118 Digital
SYS 2 Liquid Line
Solenoid Valve or EEV
Pilot Solenoid
P47 119 Digital
Lead System
(0=SYS 1,
1=SYS 2)
P48 120 Digital SYS 1 Comp.3 Run
P49 121 Digital SYS 2 Comp. 3 Run
P50 122 Digital
Chilled Liquid Type
(0=Water, 1=Glycol)
P51 123 Digital
Ambient Control Mode
(0=Std. Ambient,
1=Low Ambient)
P52 124 Digital
Local/Remote
Control Mode
(0=Local,
1=Remote)
P53 125 Digital
Units
(0=Imperial, 1= SI)
P54 126 Digital
Lead/Lag Control
Mode
(0=Manual,1= Remote)
P55 127 Digital ----
P56 128 Coded
* SYS 1
Operational Code
P57 129 Coded
* SYS 1
Fault Code
P58 130 Coded
* SYS 2
Operational Code
P59 131 Coded
* SYS 2
Fault Code
ISN
PAGE
CHARACTER TYPE DATA
P60 132 Coded ----
P61 133 Coded
SYS 1 Condenser
Fan Stage
P62 134 Coded ----
P63 135 Coded
SYS 2 Condenser
Fan Stage
P64 136 Coded ----
P65 137 Coded
Unit Control Mode
(0=Leaving Water,
1=Return Water,
2=Discharge Air,
3=Suction Press.,
4=Cooling
5=Heating)
P66 138-141 Analog Anti-Recycle Timer
P67 142-145 Analog
Leaving Chilled Liquid
Temp. Cutout
P68 146-149 Analog
Low Ambient
Temp. Cutout
P69 150-153 Analog ----
P70 154-157 Analog
Low Suction
Pressure Cutout
P71 158-161 Analog
High Discharge
Pressure Cutout
P72 162-165 Analog Setpoint
P73 166-169 Analog Cooling Range
P74 170-173 Analog ----
P75 174-177 Analog ----
P76
178-181
Analog
SYS 1 Discharge
Temp.
(EEV Only-Optional)
P77 182-185 Analog
SYS 1 Discharge
Superheat
(EEV Only- Optional)
P78 186-189 Analog
SYS 2 Discharge
Temp.
(EEV Only- Optional)
P79 190-193 Analog
SYS 2 Discharge
Superheat
(EEV Only- Optional)
P80 194 Digital ----
P81 195 Digital ----
P82 196 Digital ----
P83 197 Digital ----
P84 198 Digital ----
* The operational and fault codes sent to ISN pages 56 through 59 are dened in Table 42. Note that this table of fault and operational codes
is for all DX products.
