Refrigeration unit
Series Zero Direct-Drive
Z200 | Z250 | Z350 | Z380
Z380 Multi
INSTALLATION MANUAL
rev.01
3.3 Unpacking the unit
To unpack the unit proceed as follows:
• Carefully remove the upper and side structures of the packaging crate, then remove the front panel
and the installation kit components supplied with the unit.
• Remove the coatings and accessories of the unit present.
• Remove the dividing box (1, Figure 43), then remove evaporator (2).
Figure 43 - Unpacking the evaporator
