Refrigeration unit
Series Zero Direct-Drive
Z200 | Z250 | Z350 | Z380
Z380 Multi
INSTALLATION MANUAL
rev.01
3.10.2 Discharge heater installation
In order to prevent the formation of ice inside the condensate drain hoses, it is possible to install a defrost
resistance, if supplied.
• The drain resistance ES (6, Figure 62) must be installed in parallel to the defrosting valve YS using
the "Y" bridle supplied.
• To fix the resistance to the evaporator lid, use aluminium tape, as shown in Figure 64.
Figure 64 - Discharge heater mounting
