3.5 Lifting the condenser unit
To lift the condenser unit proceed as follows:
• Remove both side frames, as indicated in paragraph 3.4.1.
• Remove the lid.
• Remove the lid seal (1,Figure 50) and (2).
NOTE
Keep the seals in a safe place.
Figure 50 - Lid seals
