The standard overheating values are as follows: These values may vary depending on the application and
model of the unit.
Cold room
temperature
Overheating
0°C (32°F) 8K (14°F)
- 20°C (- 4°F) 4K (7°F)
Figure 72 - expansion valve adjustment
