Zebra CC6000 User Manual

DataWedge
101
47.Aim the exit window at the barcode.
Figure 67 Sample Barcode
48.Press and hold the scan button.
The red laser aiming pattern turns on to assist in aiming. Ensure that the barcode is within the area formed
by the aiming pattern. The LED light red to indicate that data capture is in process.
49.The LED lights green, a beep sounds and the device vibrates, by default, to indicate the barcode was
decoded successfully.The LED lights green and a beep sounds, by default, to indicate the barcode was
decoded successfully. The formatted data 000129X<space>appears in the text field.
Scanning a Code 39 barcode of 1299X15598 does not transmit data (rule is ignored) because the barcode
data did not meet the length criteria.
Figure 68 Formatted Data
1299X1559828

Zebra CC6000 Specifications

General

Megapixel	5 MP
Supported video modes	1080p
Operating system version	11
Operating system installed	Android
Product color	Black
Display diagonal	10.1 \
Display resolution	1280 x 800 pixels
Display aspect ratio	16:10
Connectivity technology	Wired & Wireless
Number of displays supported	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Networking standards	IEEE 802.3at
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Speaker power	2 W
Number of speakers	2
Compatible memory cards	MicroSD (TransFlash)
AC adapter input voltage	110/220 V
AC adapter output current	3 A
AC adapter output voltage	5.4 V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176920

Weight and Dimensions

Depth	201 mm
Width	278 mm
Height	36 mm
Weight	980 g
