Zebra CC6000 User Manual

DataWedge
70
In Button mode, the user can place DCP in full screen mode by dragging the button over Fullscreen mode.
The overlay covers the screen.
Figure 54 Maximized DCP
Swipe down to return to button mode.
Barcode Input
Use the Barcode Input options to configure the Barcode Scanner Input Plug-in for the profile.
Enabled
Enables or disables this plug-in. A check in the checkbox indicates that the plug-in is enabled.
Scanner Selection
Configures which scanning device to use for barcode data capture when the profile is active.
• Auto - The software automatically determines the best scanning device.
• Camera Scanner - Scanning is performed with the rear-facing camera.
• 2D Barcode Imager - Scanning is performed using the 2D Imager.
• Bluetooth Scanner - Scanning is performed using the optional Bluetooth scanner.
• RS6000 Bluetooth Scanner - Scanning is performed using the RS6000 Bluetooth scanner.
• DS3678 Bluetooth Scanner - Scanning is performed using the DS3678 Bluetooth scanner.
• LI3678 Bluetooth Scanner - Scanning is performed using the DS3678 Bluetooth scanner.
Auto Switch to Default on Event
This feature configures DataWedge to select an external scanner as the default scanning device immediately
upon connection and revert to a built-in scanner when the external scanner is disconnected. External scanners
include those connecting by Bluetooth, serial cable or snap-on module. Disabled by default. This is only
available when Scanner Selection is set to Auto.

Zebra CC6000 Specifications

General

Megapixel	5 MP
Supported video modes	1080p
Operating system version	11
Operating system installed	Android
Product color	Black
Display diagonal	10.1 \
Display resolution	1280 x 800 pixels
Display aspect ratio	16:10
Connectivity technology	Wired & Wireless
Number of displays supported	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Networking standards	IEEE 802.3at
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Speaker power	2 W
Number of speakers	2
Compatible memory cards	MicroSD (TransFlash)
AC adapter input voltage	110/220 V
AC adapter output current	3 A
AC adapter output voltage	5.4 V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176920

Weight and Dimensions

Depth	201 mm
Width	278 mm
Height	36 mm
Weight	980 g
