Zebra CC6000 User Manual

DataWedge
71
This helps reduce scanning workflow interruptions when a Bluetooth scanner is introduced and/or it becomes
disconnected due to losing power or moving out of range.
For Bluetooth scanners, if the device was not previously paired, a pairing barcode displays prior to automatic
connection.
• Disabled - No scanner switching occurs when an external scanner is connected or disconnected (default).
• On connect - Selects the external scanner as the default scanning device immediately upon connection.
• On disconnect - Reverts to a built-in scanner based on its position in an internally managed scanner list
(which varies by host device). This is usually the scanner most recently used prior to the external
connection (see notes below).
• On connect/disconnect - Selects an external scanner as the default scanning device immediately upon
connection. Upon disconnection, reverts to the scanner set as the default prior to the external connection.
NOTE: The system selects the default scanner based on the connection state and the scanner's position in an internally
managed scanner list. If the newly connected scanner is lower in the scanner list than the one currently selected as the de-
fault scanner, the newly connected scanner becomes the default scanner.
On devices with only one built-in scanner or imager, On disconnect reverts to that built-in scanner or imager.
Configure Scanner Settings
Select Configure Scanner Settings to set the following:
• Select scanner to set parameters
• Decoders
• Decoder params
• UPC/EAN params
• Reader params
• Scan params
• UDI params
• Basic Multibarcode params
• Keep enabled on suspend
Decoders
Configures which barcode decoders are enabled or disabled. For best performance disable all unnecessary
decoders.
Touch Decoders. The Barcode input screen appears. A check in the checkbox indicates that the decoder is
enabled. By default the most commonly used decoders are enabled (shown below with an asterisk). The
supported decoders are:
NOTE: DataWedge supports the decoders listed below but not all are validated on this device.

Zebra CC6000 Specifications

General

Megapixel	5 MP
Supported video modes	1080p
Operating system version	11
Operating system installed	Android
Product color	Black
Display diagonal	10.1 \
Display resolution	1280 x 800 pixels
Display aspect ratio	16:10
Connectivity technology	Wired & Wireless
Number of displays supported	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Networking standards	IEEE 802.3at
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Speaker power	2 W
Number of speakers	2
Compatible memory cards	MicroSD (TransFlash)
AC adapter input voltage	110/220 V
AC adapter output current	3 A
AC adapter output voltage	5.4 V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176920

Weight and Dimensions

Depth	201 mm
Width	278 mm
Height	36 mm
Weight	980 g
