Zebra CC6000 User Manual

Technical Specifications
147
Decode Distances
CC6000 - SE4710 Scan Engine
Table 11 lists the typical distances for selected barcode densities when scanning with the CC6000. The
minimum element width (or “symbol density”) is the width in mils of the narrowest element (bar or space) in the
symbol.\
Table 11 CC6000 - SE4710 Decode Ranges
Barcode Type
Near Distance Far Distance
Typical Typical
4 mil
Code 39
3.3 in / 8.4 cm 8.8 in / 22.4 cm
5 mil
Code 128
2.8 in / 7.1 cm 8.2 in / 20.8 cm
5 mil
Code 39
2.0 in / 5.08 cm 13.5 in / 34.3 cm
5mil
PDF417
3.1 in / 7.9 cm 7.5 in / 19.0 cm
10 mil
Data Matrix
2.9 in / 7.4 cm 10.1 in / 25.7 cm
100% UPCA 1.8 in / 4.6 cm* 24.0 in / 60.9 cm
20.0mil
Code 39
2.0 in / 5.08 cm* 26 in / 66.0 cm
*Limited by width of barcode in field of view.
Note: Photographic quality barcode at 15° tilt pitch angle under 30 fcd ambient illumination.

Zebra CC6000 Specifications

General

Megapixel	5 MP
Supported video modes	1080p
Operating system version	11
Operating system installed	Android
Product color	Black
Display diagonal	10.1 \
Display resolution	1280 x 800 pixels
Display aspect ratio	16:10
Connectivity technology	Wired & Wireless
Number of displays supported	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Networking standards	IEEE 802.3at
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Speaker power	2 W
Number of speakers	2
Compatible memory cards	MicroSD (TransFlash)
AC adapter input voltage	110/220 V
AC adapter output current	3 A
AC adapter output voltage	5.4 V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176920

Weight and Dimensions

Depth	201 mm
Width	278 mm
Height	36 mm
Weight	980 g
