Zebra CC6000 User Manual

Technical Specifications
146
Peripherals and Accessories
Accessories Additional accessories can be integrated using USB and Bluetooth interface
Mounting Options Integrated standard VESA mount; conforms to the VESA 75 mm x 75 mm
mounting standard for attachment of third party, off-the-shelf mounting
solutions; four (4) M4 x 8 mm max insert distance
2D Imager Engine (SE2100) Specifications
Field of View Horizontal - 41.5°
Vertical - 31.7°
Image Resolution 640 horizontal x 480 vertical pixels
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Sunlight: 1,000 ft. candles (10,764 lux)
Focal Distance From front of engine: 10.7 cm (4.2 inches)
Aiming Element None
Illumination System Ultra white LED
Table 10 Data Capture Supported Symbologies
Item Description
1D Barcodes Code 128, EAN-8, EAN-13, GS1 DataBar Expanded, GS1 128, GS1 DataBar
Coupon, UPCA, Interleaved 2 of 5, UPC Coupon Code
2D Barcodes PDF-417, QR Code, Digimarc, DotCode (CC6000 only)
Table 9 CC600 Technical Specifications (Continued)
Item Description

Zebra CC6000 Specifications

General

Megapixel	5 MP
Supported video modes	1080p
Operating system version	11
Operating system installed	Android
Product color	Black
Display diagonal	10.1 \
Display resolution	1280 x 800 pixels
Display aspect ratio	16:10
Connectivity technology	Wired & Wireless
Number of displays supported	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Networking standards	IEEE 802.3at
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Speaker power	2 W
Number of speakers	2
Compatible memory cards	MicroSD (TransFlash)
AC adapter input voltage	110/220 V
AC adapter output current	3 A
AC adapter output voltage	5.4 V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176920

Weight and Dimensions

Depth	201 mm
Width	278 mm
Height	36 mm
Weight	980 g
