Zebra DS4308 Reference Guide

A - 2 DS3408 Product Reference Guide
Decoding Preferences
Focus Mode F0h A6h Far Focus 5-3
Decoding Illumination F0h 2Ah Enable 5-4
Decode Aiming Pattern F0h 32h Enable 5-4
Low Light Enhancement F1h 64h Disable 5-5
Presentation Mode Field of View F1h 61h Default (Reduced) 5-5
Keyboard Wedge Host Parameters
Keyboard Wedge Host Type IBM PC/AT& IBM PC
Compatibles
1
6-4
Country Types (Country Codes) North American 6-5
Ignore Unknown Characters Transmit 6-7
Keystroke Delay No Delay 6-7
Intra-Keystroke Delay Disable 6-8
Alternate Numeric Keypad Emulation Disable 6-8
Caps Lock On Disable 6-9
Caps Lock Override Disable 6-9
Convert Wedge Data No Convert 6-10
Function Key Mapping Disable 6-10
FN1 Substitution Disable 6-11
Send and Make Break Send 6-11
RS-232 Host Parameters
RS-232 Host Types
Standard
1
7-6
Baud Rate 9600 7-7
Parity Type None 7-9
Stop Bit Select 1 Stop Bit 7-10
Data Bits 8-Bit 7-10
Check Receive Errors Enable 7-11
Hardware Handshaking None 7-12
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Zebra DS4308 Specifications

General

Sealing	IP42
Connectivity	USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Decode Capability	1D, 2D, PDF417
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Operating Temperature	32° to 104° F/0° to 40° C
Storage Temperature	-40° to 158° F/-40° to 70° C
Humidity	5% to 95% (non-condensing)
Weight	5.7 oz./161.9 g
Dimensions	6.5 in. H x 2.6 in. W x 3.6 in. D 16.5 cm H x 6.6 cm W x 9.1 cm D
