7 - 12 LS2208 Product Reference Guide
Emulate Keypad
Enable this to send all characters as ASCII sequences over the numeric keypad. For example, ASCII A transmits
as “ALT make” 0 6 5 “ALT Break”.
*Disable Keypad Emulation
Enable Keypad Emulation
USB Keyboard FN 1 Substitution
This option applies only to the USB HID Keyboard Emulation device. When enabled, this allows replacing any FN
1 characters in an EAN 128 bar code with a Key Category and value chosen by the user (see FN 1 Substitution
Values on page 13-6 to set the Key Category and Key Value).
Enable
*Disable

Table of Contents

Other manuals for Zebra LS2208

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra LS2208 and is the answer not in the manual?

Zebra LS2208 Specifications

General IconGeneral
Scan TechnologyLaser
ConnectivityWired
Scan PatternSingle line
Drop SpecificationWithstands multiple 5 ft./1.5 m drops to concrete
Scanner TypeHandheld
Scan Rate100 scans per second
Humidity5% to 95% (non-condensing)
Interface OptionsUSB, RS-232, Keyboard Wedge
Decode Capability1D barcodes
Dimensions15.2 cm H x 6.3 cm W x 8.4 cm D
Weight146 g
Operating Temperature0°C to 50°C
Resolution5 mil
Supported BarcodesUPC/EAN, Code 39, Code 128, GS1 DataBar
Storage Temperature-40°C to 70°C
