Zebra LS2208 Reference Guide

Appendix A Standard Default Parameters
Table A-1 Standard Default Parameters Table
Parameter Default Page Number
User Preferences
Set Default Parameter All Defaults 4-3
Beeper Tone Medium 4-4
Beeper Volume High 4-5
Power Mode Continuous On 4-6
Laser On Time 3.0 Sec 4-7
Beep After Good Decode Enable 4-8
Timeout Between Decodes
Time-out Between Same Symbol 0.6 sec
4-9
Time-out Between Different Symbols 0.2 sec 4-9
Keyboard Wedge Host Parameters
Keyboard Wedge Host Type
IBM PC/AT& IBM PC Compatibles
1
5-4
Country Types (Country Codes) North American 5-5
Ignore Unknown Characters Transmit 5-7
Keystroke Delay No Delay 5-8
Intra-Keystroke Delay Disable 5-9
Alternate Numeric Keypad Emulation Disable 5-9
Caps Lock On Disable 5-10
1
User selection is required to configure this interface and this is the most common selection.

Zebra LS2208 Specifications

General

Scan Technology	Laser
Connectivity	Wired
Scan Pattern	Single line
Drop Specification	Withstands multiple 5 ft./1.5 m drops to concrete
Scanner Type	Handheld
Scan Rate	100 scans per second
Humidity	5% to 95% (non-condensing)
Interface Options	USB, RS-232, Keyboard Wedge
Decode Capability	1D barcodes
Dimensions	15.2 cm H x 6.3 cm W x 8.4 cm D
Weight	146 g
Operating Temperature	0°C to 50°C
Resolution	5 mil
Supported Barcodes	UPC/EAN, Code 39, Code 128, GS1 DataBar
Storage Temperature	-40°C to 70°C
