Zebra LS2208

Miscellaneous Scanner Options 13 - 7
Synapse Interface
The auto-detection of a Synapse cable varies in duration depending on the type of Synapse connection. If a
scanner is connected to another scanner using a Synapse cable, use the Auxiliary Synapse Port connection. In all
other cases, when using the cable, Zebra recommends the default setting.
To disconnect and reconnect the scanner from a Synapse cable that is connected to a live host via a Synapse, use
the Plug and Play setting. Do not change this setting from the default if an on-board wedge host is enabled.
“Plug and Play” Synapse Connection
*Standard Synapse Connection
Auxiliary Synapse Port Connection
