4 - 4 LS2208 Product Reference Guide

Beeper Tone

To select a decode beep frequency (tone), scan the Low Frequency, Medium Frequency, or High Frequency bar

code.

Low Frequency

*Medium Frequency

(Optimum Settings)

High Frequency
