Zebra LS2208 - EAN-13, 100 %; Code 128; Interleaved 2 of 5; GS1 DataBar-14

To Next Page

To Previous Page

C - 2 Symbol LS2208 Product Reference Guide

EAN-13, 100 %

Code 128

Interleaved 2 of 5

GS1 DataBar-14

12345678901234567890123456789012345678901234

12345678901231

NOTE You must enable GS1 DataBar-14 to read the bar code below (see Enable GS1 DataBar-14 on page

12-52).
