Zebra MC67 User Manual

7 - 26 MC67 User Guide
1. Tap and hold on OBEX Object Push and select Connect.
Figure 7-25 OBEX Object Push Window
2. In the Action: drop-down list, select Send Contact Information.
3. Tap .
4. Select a contact to send to the other device.
5. Tap OK.
6. Tap OK to send the contact to the other device and display a confirmation dialog box on the other device to
accept the contact. A Send Contact dialog appears.
7. Tap Ok.
Swapping Contacts
To swap contacts with another device:
1. Tap and hold on OBEX Object Push and select Connect. The OBEX Object Push window appears.
NOTE Prior to sending and receiving contacts, a default contact must be set up before attempting to send a
contact.
NOTE Prior to swapping contacts, a default contact must be set up before attempting to send a contact.
Ensure that the MC67 is connectable.

Zebra MC67 Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	-
Flash memory	2 GB
Internal memory	0.512 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	Instruments OMAP
Processor frequency	0.8 GHz
Processor manufacturer	Texas Instruments
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3600 mAh
Data network	4G, HSPA+
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Keyboard layout	QWERTY
Operating system installed	Windows Mobile 6.5

Weight and Dimensions

Depth	33.5 mm
Width	77 mm
Height	162.2 mm
Weight	385 g
