5 - 8 RFD8500 User Guide
SETTINGS
Touch SETTINGS to access the SETTINGS tab.The SETTINGS tab allows the user to configure the
scanner.Table 5-2 describes the options in this view.
Table 5-3 Active Scanner Screen - SETTINGS Tab
Field Description
Symbologies Touch Symbologies to display the bar code types
supported by the scanner.
• For each bar code type, slide the OFF/ON
switch to the applicable position.
• Select Permanent to save the settings.
Symbology Notes:
1. For a complete list of symbologies and their
corresponding settings (if any), configure the
device via 123Scan
2
.
2. When setting the Inter Character Delay for HID
only, set the delay in milliseconds between
emulated keystrokes. When pairing with an
Android device, set the Inter Character Delay
to 70 ms to avoid data loss.
Beeper Touch Beeper to display the beeper types supported
by the scanner.
• Select the applicable beeper volume, and
beeper frequency.
Miscellaneous Options Touch any of the following options to enable, or
disable the feature.
• Enable scanning
• Disable scanning
• AIM On (auto aim on displays the red
illumination before pulling the trigger)
• Aim Off
• Vibration Feedback

Zebra RFD8500 Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D/2D
Read rate (max)	600 reads/s
Bluetooth version	2.1+EDR
Operating frequency	865 - 868 MHz
Standard interfaces	Bluetooth
Product color	Gray
LED indicators	Yes
Protection features	Dust resistant, Splash proof
Battery capacity	4410 mAh
Power source type	Battery
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	5 - 85 %
Mobile operating systems supported	Android 4.4, Android 5.0, Android 5.1, iOS 8.0, iOS 8.2, iOS 9.0
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	130 mm
Width	185 mm
Height	80 mm
Weight	430 g
