OPERATION
Axiovert 200 Axiovert 200 Carl Zeiss
B 40-080 e 03/01 3-11
Centering screw for condenser (3-1/18 and 22)
− Screws for condenser centering attached to both sides of the carrier for transmitted-light
illumination / condenser.
Lever for luminous-field diaphragm, transmitted light (3-1/20)
− Lever attached to the carrier for transmitted-light illumination / condenser which opens and closes the
transmitted-light luminous-field diaphragm to set KÖHLER illumination
− Lever in front position: luminous-field diaphragm fully opened
− Lever in rear position: luminous-field diaphragm closed
Lever for vertical adjustment of the condenser (3-1/21)
− Setting knob attached to the carrier for transmitted-light illumination / condenser which raises and
lowers the condenser to set KÖHLER illumination
Polarizer D with 2-position filter changer (3-1/17)
− The polarizer and two filter positions can be swung in and out separately. Stop position in swung-in
status.
Microscope stages with specimen holder (3-1/24)
− The specimens are mounted, positioned and fixed in position using the specimen holder.
− Equipped as follows, depending on the instrument configuration:
specimen stage 250x230 with object guide and mounting frame for object guide (M)
mechanical stage 250x230 and mounting frame for mechanical stage (K)
scanning stage
heating stage
gliding stage Z
Key "Set LM" (3-1/35)
− Stores the Light Manager values and enters the configuration mode.
Frontport (3-1/12)
− Port for the connection of documentation equipment.
Clamping screw for Frontport (3-1/31)
− Clamping screw for fixation of the camera / video adapter to the Frontport.
