Baseport (3-1/34)
− Port for the connection of documentation equipment below the Axiovert 200.
Setting knob for Frontport / Baseport / vis (3-1/32)
− Selects the beam splitting ratio for Frontport, Baseport and visual observation.
− 3 switching positions:
100 % vis (free light path);
VIS
100 % Frontport;
FP
100 % Baseport;
BP
Sideport right (3-1/5)
− Port for the connection of documentation equipment.
− Different splitting ratios for Sideport right, Sideport left and visual observation (vis), depending on the
instrument configuration.
Sideport left (3-1/29)
− Port for the connection of documentation equipment.
− Different splitting ratios for Sideport right, Sideport left and visual observation (vis), depending on the
instrument configuration.
Setting wheel for Sideport right / Sideport left / vis (3-1/30)
− Selection of beam splitting for Sideport (doc) right, Sideport (doc) left and visual (vis) observation.
− 2 or 3 switching positions with different beam splitting ratios.
− 2 switching positions with instrument configuration with Sideport 60 left:
100 % vis: 0 % doc;
20 % vis: 80 % doc left;
80
3 switching positions with instrument configuration with Sideport 60 left:
100 % vis: 0 % doc;
0 % vis: 100 % doc left;
50 % vis: 50 % doc left
50
− 3 switching positions with instrument configuration with Sideport 60 right:
100 % vis: 0 % doc;
0 % vis: 100 % doc right;
50 % vis: 50 % doc right
50
− 3 switching positions with instrument configuration with Sideport 60 left and right:
100 % vis: 0 % doc;
0 % vis :100 % doc left;
20 % vis: 80 % doc right
80
