30-36 Controller
Motor and Drive System
30
11. Place the B- busbar on to the controller.
12. Place a new O-ring (x3) on the B- busbar.
13. Install terminal bolt. Tool: 22mm 6-point
socket. Torque: 11 lb-ft (15 Nm).
CAUTION: Install the terminal bolts without
any thread locking compound.
CAUTION: Install the terminal bolts without
any CP70 (or any type of insulating
lubricant/gel/paste).
14. Place the B+ busbar on to the controller.
15. Place a new O-ring (x3) on the B+ busbar.
16. Install terminal bolt. Tool: 22mm 6-point
socket. Torque: 11 lb-ft (15 Nm).
CAUTION: Install the terminal bolts without
any thread locking compound.
CAUTION: Install the terminal bolts without
any CP70 (or any type of insulating
lubricant/gel/paste).
