30-44 Rear Sprocket
Motor and Drive System
30
7. Raise rear tire and remove rear WSS sensor
and set aside.
Note: Make sure the WSS sensor is hung up
and not straining the WSS electrical harness.
8. Lower the rear tire carefully to keep from
damaging painted surfaces.
9. Place rag over the left side of the swingarm
between the rear sprocket and the swing arm
to protect painted surfaces.
10. Roll rear tire forward.
11. Release rear brake hose from the metal
retaining clip.
12. Position the rear brake hose on top of clip.
13. Tip the top of the rear tire to the left.
