Zero SR/S User Manual

40-12 Front Suspension
Suspension
40
6. Remove left and right inner side fairings. See
Side Fairings (Inner)
, page 60.19.
7. Remove tank assembly. See Tank Removal,
page 60.10.
8. Remove headlight inner fairing. See Headlight
Inner Fairing, page 60.3.
9. Remove front wheel speed sensor (WSS)
sensor. See Wheel Speed Sensor (Front)
,
page 40.1.
10. Remove bolts (x2) securing left side of front
fender to the left front shock. Tool: T25.
Torque: 3.5 lb-ft (5 Nm).
11. Remove bolts (x2) securing right side of front
fender to the left front shock. Tool: T25.
Torque: 3.5 lb-ft (5 Nm).
12. Loosen left front suspension upper clamp
bolt. Tool: T45. Torque: 16 lb-ft (22 Nm).
13. Loosen left front suspension lower clamp bolt.
Tool: T45. Torque: 16 lb-ft (22 Nm).
14. Slide the left front suspension out through the
bottom.

Zero SR/S Specifications

General

Category	Motorcycle
Peak Power	110 hp (82 kW)
Continuous Power	54 hp (40 kW)
Torque	140 ft-lb (190 Nm)
Range (City)	161 miles (259 km)
Range (with Power Tank)	200 miles (322 km)
Top Speed (Max)	124 mph (200 km/h)
Top Speed (Sustained)	110 mph (177 km/h)
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Motor	Z-Force 75-10
Battery	ZF14.4 Lithium-ion
Range (Highway)	82 miles (132 km) at 70 mph
Seat Height	787 mm (30.9 in)
Wheelbase	1, 450 mm (57.1 in)
Front Suspension	Showa 41 mm
Rear Suspension	Showa 40mm piston, piggy-back reservoir shock
Front Brake	Dual J-Juan asymmetric piston calipers, 320 x 5 mm discs
Rear Brake	J-Juan single piston floating caliper with 240mm disc
ABS	Bosch Gen 9
Charging Time (Standard)	4.5 hours
