Zero SR/S User Manual

40-14 Front Suspension
Suspension
40
21. Remove stem nut. Tool: 41mm. Torque:
75 lb-ft (102 Nm).
22. Remove upper triple clamp (shown with stem
nut removed - upper triple clamp just sitting on
the steering shaft).
23. Remove shaft nut. Tool: Adjustable hook
spanner wrench (showing the nut - no tool in
photo is acceptable).
24. Remove lower triple clamp and discard
bearings (x2), races (x2), and seals (x2).
Note: Replace bearings (x2), races (x2), and
seals (x2) upon installation.
Installation
1. Installation is the reverse of the removal
procedure, but take note of the following
installation step.
2. Pay close attention to the order of installation
of the bearings, races, seals, steering stem
lock nut, and steering stem nut.
CAUTION: Install the steering stem lock nut
(located under the upper triple clamp) with
the bevel facing down.

Zero SR/S Specifications

General

Category	Motorcycle
Peak Power	110 hp (82 kW)
Continuous Power	54 hp (40 kW)
Torque	140 ft-lb (190 Nm)
Range (City)	161 miles (259 km)
Range (with Power Tank)	200 miles (322 km)
Top Speed (Max)	124 mph (200 km/h)
Top Speed (Sustained)	110 mph (177 km/h)
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Motor	Z-Force 75-10
Battery	ZF14.4 Lithium-ion
Range (Highway)	82 miles (132 km) at 70 mph
Seat Height	787 mm (30.9 in)
Wheelbase	1, 450 mm (57.1 in)
Front Suspension	Showa 41 mm
Rear Suspension	Showa 40mm piston, piggy-back reservoir shock
Front Brake	Dual J-Juan asymmetric piston calipers, 320 x 5 mm discs
Rear Brake	J-Juan single piston floating caliper with 240mm disc
ABS	Bosch Gen 9
Charging Time (Standard)	4.5 hours
