45-4 Brakes
Brakes
45
3. Install the upper brake pad pin (1), capturing
the anti-rattle clip first. Install the lower brake
pad pin (2), capturing the anti-rattle clip
second. Tool: T25. Torque: 6 lb-ft (8 Nm).
4. After installing new brake pads, perform the
brake pad bedding procedure. See Brake
Bedding, page 10.7.
