Zero SR/S User Manual

45-10 Brakes
Brakes
45
14. Slide rear caliper assembly toward wheel and
slide caliper bracket off of the bracket
alignment pin.
15. Remove rear brake caliper.
Installation
1. Installation is the reverse of the removal
procedure, with the exception of the following:
2. When installing the rear WSS, make sure the
alignment tab is positioned against the top
edge of the rear brake bracket as shown.
3. Confirm that the aluminum bushing from left
side (sprocket side) of the wheel is installed in
the seal prior to installation of the wheel.
4. Perform brake bleeding procedure. See Brake
Bleeding Procedure (Rear), page 10.6.
5. If new brake pads have been installed,
perform the brake pad bedding procedure.
See Brake Bedding
, page 10.7.

Zero SR/S Specifications

General

Category	Motorcycle
Peak Power	110 hp (82 kW)
Continuous Power	54 hp (40 kW)
Torque	140 ft-lb (190 Nm)
Range (City)	161 miles (259 km)
Range (with Power Tank)	200 miles (322 km)
Top Speed (Max)	124 mph (200 km/h)
Top Speed (Sustained)	110 mph (177 km/h)
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Motor	Z-Force 75-10
Battery	ZF14.4 Lithium-ion
Range (Highway)	82 miles (132 km) at 70 mph
Seat Height	787 mm (30.9 in)
Wheelbase	1, 450 mm (57.1 in)
Front Suspension	Showa 41 mm
Rear Suspension	Showa 40mm piston, piggy-back reservoir shock
Front Brake	Dual J-Juan asymmetric piston calipers, 320 x 5 mm discs
Rear Brake	J-Juan single piston floating caliper with 240mm disc
ABS	Bosch Gen 9
Charging Time (Standard)	4.5 hours
