Zero SR/S User Manual

Body
Body 60-17
60
16. While removing left outer side fairing, guide
the left front turn signal harness wires through
their access hole in the left inner side fairing.
Installation
1. Installation is the reverse of the removal
procedure, with the exception of the following:
2. Prior to installing the left outer side fairing,
install cable tie through the left outer fairing
arm cable retainer hole.
3. Prior to installing the right outer side fairing,
install cable tie through the right outer fairing
arm cable retainer hole.
4. While installing the left turn signal harness,
insert it through the cable tie attached to the
left outer fairing arm.
5. While installing the right turn signal harness,
insert it through the cable tie attached to the
right outer fairing arm.

Zero SR/S Specifications

General

Category	Motorcycle
Peak Power	110 hp (82 kW)
Continuous Power	54 hp (40 kW)
Torque	140 ft-lb (190 Nm)
Range (City)	161 miles (259 km)
Range (with Power Tank)	200 miles (322 km)
Top Speed (Max)	124 mph (200 km/h)
Top Speed (Sustained)	110 mph (177 km/h)
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Motor	Z-Force 75-10
Battery	ZF14.4 Lithium-ion
Range (Highway)	82 miles (132 km) at 70 mph
Seat Height	787 mm (30.9 in)
Wheelbase	1, 450 mm (57.1 in)
Front Suspension	Showa 41 mm
Rear Suspension	Showa 40mm piston, piggy-back reservoir shock
Front Brake	Dual J-Juan asymmetric piston calipers, 320 x 5 mm discs
Rear Brake	J-Juan single piston floating caliper with 240mm disc
ABS	Bosch Gen 9
Charging Time (Standard)	4.5 hours
