Body
Body 60-21
60
13. Remove the right inner side fairing.
14. Remove long bolt (x1[blue arrow]) and short
bolts (x2[orange arrows]) securing the upper
half of the left inner side fairing to the
motorcycle frame and bodywork. Tool: T25.
Torque: 3 lb-ft (4 Nm).
Note: Take note of length of the bolts.
15. Remove the left inner side fairing.
Installation
1. Installation is the reverse of the removal
procedure.
