Electrical
Kickstand Switch 70-35
70
10. Disconnect kickstand harness connector.
11. Cut cable tie securing the kickstand harness
to the left doubler plate.
Note: Replace cable tie during the installation
process.
12. Remove bolts (x2) securing kickstand to the
left doubler plate. Tool: T50. Torque (both
bolts): 25 lb-ft (34 Nm).
13. Remove kickstand.
14. Remove bolts (x2) securing the brake stand
switch. Tool: 2.5mm hex wrench. Torque:
2lb-ft (3 Nm).
Installation
1. Installation is the reverse of the removal
procedure.
