Zero SR/S User Manual

25-16 Chargers
Charging System
25
18. Remove T40 bolt securing horn. Torque 8 lb-ft
(11 Nm).
19. Disconnect wires (x2) from horn.
20. Remove horn.
21. Disconnect charge outlet connector.
22. Remove T30 bolts (x2) securing HCU bracket.
Torque 6 lb-ft (8 Nm).
23. Remove T30 bolts (x2) securing HCU bracket.
Torque 6 lb-ft (8 Nm).
24. Loosen T30 bolts (x2) securing charger
connector brackets. Torque 6 lb-ft (8 Nm).
25. Remove T25 bolt from each side of the
charger mount. Torque 6 lb-ft (8 Nm).
26. Remove T30 bolts (x4) securing the charger
support bracket to frame. Torque 8 lb-ft
(11 Nm).

Zero SR/S Specifications

General

Category	Motorcycle
Peak Power	110 hp (82 kW)
Continuous Power	54 hp (40 kW)
Torque	140 ft-lb (190 Nm)
Range (City)	161 miles (259 km)
Range (with Power Tank)	200 miles (322 km)
Top Speed (Max)	124 mph (200 km/h)
Top Speed (Sustained)	110 mph (177 km/h)
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Motor	Z-Force 75-10
Battery	ZF14.4 Lithium-ion
Range (Highway)	82 miles (132 km) at 70 mph
Seat Height	787 mm (30.9 in)
Wheelbase	1, 450 mm (57.1 in)
Front Suspension	Showa 41 mm
Rear Suspension	Showa 40mm piston, piggy-back reservoir shock
Front Brake	Dual J-Juan asymmetric piston calipers, 320 x 5 mm discs
Rear Brake	J-Juan single piston floating caliper with 240mm disc
ABS	Bosch Gen 9
Charging Time (Standard)	4.5 hours
