Zetor Proxima 100 User Manual

122
ADDITIONAL WEIGHTS
P11NE551 P11NE551 E553
WEIGHTS IN FRONT OF THE
BONNET MASK
Weights in front of the mask
Combination of
weights (pcs)
Weights
(kg)
4+1 4x50 + 66 266
8+1 8x50 + 66 466
WEIGHTS OF THE FRONT THREE-
POINT HITCH
Weights of the front three-point hitch
Combination of
weights (pcs)
Weights
(kg)
10 10x28 280
WEIGHTS OF REAR WHEELS
Combination of
weights (pcs)
Weights
(kg)
2+2 2x16 + 2x30 90
2+4 2x16 + 4x30 150
2+8 2x16 + 8x30 270
A - Mounting of weights for rear wheel
treads 1,350 to 1,500mm
B - Mounting of weights for rear wheel
treads 1,575 to 1,800mm

Zetor Proxima 100 Specifications

General

Engine Power	100 hp
Fuel Tank Capacity	150 L
Power (hp)	100 hp
Displacement (L)	4.156 L
Rated speed (rpm)	2200 rpm
Max. speed (km/h)	40 km/h
Hydraulic System	Open center
Engine Type	4-cylinder diesel
