59
DRIVING OPERATION
G150 C168b E149a
SELECTION OF ROAD OR REDUCED
SPEEDS
H
road speeds
N
neutral
L
reduced speeds
When reduced speeds are used, gear
change is the same as in road speeds.
Considering low speed of the tractor,
change nearly always means moving off
from rest.
The change lever from road to
reduced speeds may be moved
only if the tractor is in rest.
GEAR CHANGE
Gears are changed using the main
change lever.
A - Standard type of the tractor
Gears and drive direction are changed
using the change lever
B - The tractor is equipped with
reversal.
Gears are changed with the main
change lever, drive direction is changed
with the reversal lever.
SELECTION OF DRIVE DIRECTION -
*REVERSAL LEVER
F - forward drive; the lever is in the front
position
R -backward drive; the lever is in the
back position
Change is carried out when the tractor is
in rest.
