Zetor Proxima 100 User Manual

73
TRANSPORT USE
Before a drive make sure that the
technical condition ensures safe
operation of the tractor.
In case that a trailer or implement is
coupled, verify its coupling and proper
fixing of the load. Never get out of the
tractor to couple a trailer yourself. Pay
also attention to your assistant.
Page
Front hook................................................................................................................. 74
Multi-level quick-adjustable hitch CBM......................................................................74
Height adjustment and dismounting of the multi-level hitch CBM..............................74
Automatic hitch of the multi-level hitch device CBM..................................................75
Modular system of hitches for trailers and semi-trailers ............................................75
Bracket Module of pivoted pull bar............................................................................ 75
Pivoted pull bar .........................................................................................................75
Bracket Module of pivoted pull bar with fixed pin ......................................................76
Bracket module with ball ø 80...................................................................................76
Towing bar...............................................................................................................76
Coupling of a single-axle trailer................................................................................. 77
Uncoupling of a single-axle trailer ............................................................................. 77
Hitch CBM for single-axle trailers..............................................................................77
Coupling with a trailer or semi-trailer.........................................................................78
Hook of the mounting for a single-axle trailer............................................................ 78
Maximum permitted vertical static loading of hitches for trailers and semi-trailers.... 79

Zetor Proxima 100 Specifications

General

Engine Power	100 hp
Fuel Tank Capacity	150 L
Power (hp)	100 hp
Displacement (L)	4.156 L
Rated speed (rpm)	2200 rpm
Max. speed (km/h)	40 km/h
Hydraulic System	Open center
Engine Type	4-cylinder diesel
