Zetor Proxima 100 User Manual

168
MAINTENANCE INSTRUCTIONS
F206
 FRONT OUTPUT SHATF
The inspection and oil filling plug is lo-
cated on the front output shaft face.
Note: A plug or hollow screw is installed
according to the particular design.
A hollow screw of the oil cooler hose is
installed instead of the inspection and fill-
ing plug on the front output shaft with
standard direction of rotation. Carry out
checks after removal of the hollow
screw.
After screwing out the inspection
plug the level of oil shall reach
the lower edge of the inspection
hole.
With replacement of oil it is necessary to
clean the screen oil cleaner (2). This
screen-type cleaner is accessible after
removal of the retaining ring and the lid.

Zetor Proxima 100 Specifications

General

Engine Power	100 hp
Fuel Tank Capacity	150 L
Power (hp)	100 hp
Displacement (L)	4.156 L
Rated speed (rpm)	2200 rpm
Max. speed (km/h)	40 km/h
Hydraulic System	Open center
Engine Type	4-cylinder diesel
