Section 10.0
MAN 06–0017H
ZIEHM QUANTUM User’s Manual Page 157 of 220
enter the configuration screen of the Desk view.
ERASING DISK
• Press the ERASE DISK button and respond to the message box YES to erase the
Disk and NO to cancel the operation. After you press the YES button you will be
asked again a second time to make sure you wish to proceed with Disk Erase
operation.
• Once the disk operation has been completed, the user will be instructed to turn
off the c-arm and re-start the c-arm. After system is turned off Wait at least 10
seconds before turn on power again.
• After you turn on the power and the system has fully booted, press the hand
switch to start fluoroscopic exposure for 1 second, release hand switch and then
store the image by pressing the STORE button on the main touch screen. The
right monitor will display the image and small icon on the bottom.
ACTIVATING DATABASE
• Go to the configuration screen and perform the Erase Disk operation a second
time and then turn off power when directed to do so.
• Wait 10 seconds and then press the power on switch again. Wait until the system
is fully booted.
• Now press the NEW PATIENT button to establish a new patient in the image
system database. Recommend entering for patient name “TEST” and For ID
123.
• Now press the SAVE button to save patient file.
• Press the hand switch to start fluoroscopic exposure for 1 second, release hand
switch and then store the image by pressing the STORE button on the main
touch screen. The right monitor will display the image and small icon on the
bottom.
• System is now ready to enter additional patients and store images.
CAUTION
The Administrator should use caution when performing the Erase Disk operation as this
operation if not performed correctly may cause incorrect data base operations.
