Ziehm Imaging, Inc. QUANTUM User Manual

Section 15.0
MAN 06–0017H
ZIEHM QUANTUM User’s Manual Page 210 of 220
18 Laser label for the Generator
*Only on systems with Laser
device
*Qty 1 for Laser LG
Location see fig 15.2
*
19
Laser Label for the image
intensifier
*Only on systems with Laser
device
*Qty 1 for Laser LC
Image intensifier See Fig 15.1
*
20 Located on side of the Mobile
Stand above XPO Connector
Fig 15.1
1
21
If sold in Canada this label must
be attached next to item 20
Located below XPO Connector
Fig 15.1
1
22
Equipment bonding
Fig 15.1
1
